The Product Life Cycle of an Electronics product starts from a product
idea. This idea is then brainstormed and the most feasible approach is Architected and the
schematics for the same is designed after required simulations. The schematics is then
imported into a layout file where the board outlines and the footprints are added. Finally
the gerber files are generated once the routing is completed. After this prototypes are made
and tested and feedbacks incorporated back in the design. Then the design is ready for
production. Also these updated prototypes are taken through certifications if the customers
ask for the same.
Our years of experience taking multiple products via the life cycle enables us to
seamlessly
take you through this journey and make your product to market time faster.
➢ Requirement and Feasibility Study.
➢ Finalization of Idea and milestones.
➢ Architecture development.
➢ Schematic Design / Simulation.
➢ Test Plan documentation and
preparation.
➢ Verification, Validation and Necessary
Certification for Products.
➢ Design using Microcontrollers and microprocessors from TI, ST micro, ATMEL,
MICROCHIP, MARVELL and Intel etc...
➢ Wi-Fi, Bluetooth/BLE, ZigBee, RFID,GPS, GSM, CAN based interfaces and
module design.
➢ USB, I2C, SPI, UART, Ethernet, etc
➢ High Speed, Analog, mixed signal and RF design capabilities
➢Digital Design : Tablets, IP Cameras, web cameras, handheld devices, etc.
➢Telecom Design : DSL Modems, IPD SLAM, IP PBX, VoIP Phones, etc.
➢ Power Electronics : SMPS, Power Converters, UPS etc..
➢ Robotic Design :Vacuum Cleaners and Telepresence Robots.
➢ LED Based lighting and Display – Smart Switch, electronic measuring
devices.
